Datalogic Gryphon GD4130-BK USB Scanner ***Used***

Extremely snappy reading performance with speeds up to 325 reads/secondThe Datalogic Gryphon I GD4100 linear imaging readers provide advanced reading performance and decoding for a wide variety of applications. The Gryphon I GD4100 readers' ability to capture barcodes from near contact to over 1.0 m / 3.9 ft. increases productivity and improves ergonomics for users. A wide scan angle reads very wide codes and renewed decoding capabilities increase throughput on hard-to-read, poor or damaged codes. All of these features combined with low-resolution decoding for labels as small as 3 mils, establishes the Gryphon I GD4100 readers as high-performance products and powerful data capture solutions. Datalogic's exclusive patented 'Green Spot' for good-read feedback directly on the code is ideal under dim lighting conditions or noisy environments. The Green Spot, together with the fast reading and decoding capabilities make the Datalogic Gryphon I GD4100 readers the best choice to improve productivity in retail and office environments, hospitals, pharmacies, warehouses and manufacturing plants.

Technical Information

Barcode Dimension: 1D
Scan Pattern: Linear
Scan Rate: 325 scan/s
Connectivity Technology: Cable
Scanning Distance: 23.60"
Light Source: LED
Image Sensor: CCD
Barcode Symbology Supported:

Postal Codes: China Post
1D / Linearcodes:
Autodiscriminates All Standard 1D Codes
GS1 Databar Linearcodes
Stacked Codes:
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
Postal Codes: China Post
1D / Linearcodes:
Autodiscriminates All Standard 1D Codes
GS1 Databar Linearcodes
Stacked Codes:
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional

Maximum Scan Resolution: 3 mil
Depth of Field:

2.30" – 7"@5 mil
1.40" – 11.70"@7.50 mil
0.80" – 17.70"@10 mil
1.20" – 23.40"@13 mil
1.20" – 31.20"@20 mil

General Information

Product Type: Handheld Barcode Scanner
Product Series: GD4100
Brand Name: Datalogic
Manufacturer: Datalogic S.p.A
Product Model: Gryphon GD4130
Product Name: Gryphon GD4130 Barcode Reader
Product Line: Gryphon

Physical Characteristics

Height: 7.1"
Width: 2.8"
Depth: 3.9"
Color: Black
Weight (Approximate): 6 oz

Interfaces/Ports

Host Interface: Multi-interface

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: China RoHS
Additional Information:

Supported Interfaces:
IBM 46XX
USB
Keyboard Wedge
Wand
